Description
FEATURES
- High-performance STM32 F722 MCU with speeds up to 216MHz.
- ICM42688P gyroscope, independent low-noise power supply.
- Built-in analog video OSD, 16M black box,5UART ports, 8PWM output ports, 2ADC ports, 1 I2C port.
- Dual high power synchronous rectifier BEC, supports up to 36V input and provides stable 5V/10V 3A output.
- Modular cable design, with a reliable locking structure, can be installed quickly while retaining full-featured pads on the back, providing more expansion support.
- Single-side layout, lower mounting height, 6-layer PCB, isolated ESC interference.
- PC case is impact resistant and easy to disassemble, isolated from dust and grass clippings
SPECIFICATIONS
- MCU： STM32F722RET6
- GYRO： ICM42688P
- BLACKBOX ：16MB FLASH
- BEC：INPUT 7-36V / 3-6S LIPO，OUTPUT 1 5V 3A，OUTPUT 2 10V 3A
- PORT： 8×PWM 5×UART 1×I2C
- ADC： V-BATT / CURR-ESC
- LED： WS2812 LED STRIP
- SIZE： 36.5mm*37mm*5.2mm
- BARO：BMP280
- MOUNTING HOLES：30.5*30.5mm
- TARGET： RUSH_BLADE_F7_HD WEIGHT 11g(without cable)
INCLUDES
- 1 x RUSH BLADE F722 V2 30×30 Flight Controller For DJI HD
- 2 x 60MM UART Cable
- 2 x 60MM UART Cable
- 1 x 60MM ESC Cable
- 1 x 60MM ESC Cable
- 1 x 60MM ESC Cable
- 1 x 60MM LED Cable
- 1 x 90MM HDCable
- 1 x 110MM Air Unit Cable
- 5 x 8MM Grommet
- 5 x 5MM Grommet
