Description

SPECIFICATIONS

Wheelbase: Bottom Plate

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Frame

Tool Supplies: Cutting

Technical parameters: Value 2

Size: 25.5*25.5mm

Remote Control Peripherals/Devices: Remote Controller

Recommend Age: 12+y

RC Parts & Accs: Antennas

Quantity: 1 pcs

Origin: Mainland China

Model Number: BLITZ F411 1S 5A

Material: Metal

Four-wheel Drive Attributes: Assemblage

For Vehicle Type: Airplanes

Certification: CE

Brand Name: IFLIGHT

：

TOP FEATURES:

• Built in 2.4G ELRS w/SMD Antenna

• Support BLHeliSuite programmable

• 5A continuous current

• Super light only 4.8g

• MCU：STM32F411

• Power supply: 1S

• Gyro: BMI270

• Built-in VTX

FC // BLITZ F411 1S 5A Whoop AIO Board

• Weight: 4.8g (with power cable. VTX. and VTX antenna)

• Mounting pattern: 25.5*25.5mm/φ3mm （half-hole)

• FC Firmware: IFLIGHT_BLITZ_F411RX

• BEC output: 5V 500mA

• Connector: Micro-USB

• MCU: STM32F411

• INA pad: n uart2

• Barometer: NO

• Size: 29*29mm

• Gyro: BMI270

• Blackbox: NO

• NOTE: F.PORT protocol RX input support. telemetry not supported.

ESC // 5A

• Signal
