Description
Same reliable 55A ESC from T-motor combined with an updated version of F7 Flight controller with 10V output BEC that’s plug and play with the DJI Air Unit!
Specifications
FC
- MCU: STMF722RET6
- Gyro: BMI270
- Memory: 16M
- Input Voltage: 12v-25-2v (3-6S)
- BEC: 5V/2A, 10V 2A
- Dimensions: 37mm x 37mm
- Mounting Holes: 30.5mm x 30.5mm
- Weight: 8.4g
- Firmware Target: TMOTORF7 (Betaflight)
ESC
- Continuous current: 4*55A
- BLHeli_32 32bit
- Burst current: 4*75A
- BEC Output: 10V @2.0A
- Size: 45x41x7.3mm
- Weight: 17.3g (Including Heatsink)
- Support DSHOT150/300/600/1200
Includes
- T-Motor F55A PRO II + F7 HD STACK × 1
- M3×30 Screw × 4
- M3 Non-Slip Nut × 4
- M3×3 White Hollow Isolation Column × 4
- M3×3 White Hollow Isolation Column × 12
- Insulation Sheet × 1
- Electrolytic Capacitor × 1
- Power Cord × 1
- Link Board × 4 (racewire)
- Graph Connection Line × 2
- ESC Cable × 2
