RCinPOWER GTS V3 1002 FPV Drone Motor – Choose KV / Color

Description

The RCinPOWER GTS V3 1002 FPV Drone Motor is the drone motor for your toothpick / micro drone.

Features

• 2.5g in weight
• 1002 Stator
• Available in 14000KV, 19000KV, 22000KV
• Available in Teal / Blue and Orange

Specifications

14000KV

• Motor Dimensions: 13.5×7.75mm
• Max Continuous Current: 9A
• Stator Dimensions: 10x2mm
• Internal Resistance: 175mΩ
• Mounting Pattern: 9x9mm
• Shaft Diameter: 1.5mm
• ldle Current@5V: .8A
• Configuration: 9N12P
• Input Voltage: 1-2S
• Weight: 2.5g
• Kv: 14000

19000KV

• Motor Dimensions: 13.5×7.75mm
• Max Continuous Current: 11.8A
• Stator Dimensions: 10x2mm
• Internal Resistance: 89mΩ
• Mounting Pattern: 9x9mm
• Shaft Diameter: 1.5mm
• ldle Current@5V: 1.3A
• Configuration: 9N12P
• Input Voltage: 1S
• Weight: 2.5g
• Kv: 19000

22000KV

• Efficiency Current: 2-4A ( More than 84%)
• Max. Current: 14A (3S) Max.
• Max. Con. Power: 52W (3S)
• Internal Resistance: 75mΩ
• Idle Current: 1.5A @ 5V
• Stator Diameter: 10mm
• Shaft Diameter: 1.5mm
• Input Voltage: 1S Lipo
• Configuration: 9N12P
• KV: 22000KV
• Weight: 2.5g

Includes

• 1x RCINPOWER GTS V3 1002 Motor (Choose 14000KV, 19000KV, or 22000KV)
• 1x Hardware Set
