RadioMaster AG01 Gimbal – MINI CNC Hall Gimbal for TX12 / Zorro Radio Transmitter FPV Remote Controller

Description

RadioMaster AG01 Gimbal

Wheelbase: Screws

Upgrade Parts/Accessories: Adapter

Tool Supplies: Cutting

Technical parameters: Value 2

Size: AS DESCRIPTION

Remote Control Peripherals/Devices: Remote Controller

Recommend Age: 12+y

Recommend Age: 14+y

RC Parts & Accs: Connectors/Wiring

Quantity: 1 pcs

Origin: Mainland China

Model Number: RadioMaster AG01 MINI

Material: Composite Material

Four-wheel Drive Attributes: Assemblage

For Vehicle Type: Airplanes

RadioMaster AG01 MINI CNC Hall Gimbal for TX12 / Zorro Radio Transmitter Remote Controller

Introduction:

The long-awaited AG01 Mini is finally here! Custom designed for the RadioMaster Zorro and TX12. these gimbals allow for unparalleled precision and stick feel.
From the aviation-grade aluminum construction. non-contact hall sensors. and pre-installed Sticky360 Mini Gimbal Sticks. be prepared to revolutionize your compact radio experience!
Please note: AG01 MINI gimbals are expected to ship in mid May.

Key Features:
– Made with CNC processed aviation grade aluminum.
– Sticky360 Mini Gimbal Sticks as standard.
– Non contact hall sensors for accurate control inputs and precise centering.
– Quad precision bearings for unparalleled stick feel.
– Adjustable vertical travel angle (Min. 38°. Max. 54°).
– Custom designed for RadioMaster Zorro . TX12.

Specification:

Name: AG01 Mini CNC Hall Gimbal
Sensor type: Hall Sensor
Working voltage: DC 3.3V
Linearity: Real-time (No delay)
Adjustable vertical travel range: 38°—54°
Self-centering adjustment: Yes
Easy mode adjustment
Adjustable tension & ratchet: Yes
Quad bearing: Yes
Temperature range: -20°C-85°C
Size: 49*42*48mm
Weight: 42g(±0.3g)

Package Included

1 PC Version

1 * AG01 Mini Hall CNC Gimbal
1 * Hex tool
4 * Installation screw
1 * Spare normal tension spring
1 * Throttle tension screw
OR

2 PCS Version

2 * AG01 Mini Hall CNC Gimbal
2 * Hex tool
8 * Installation screw
2 * Spare normal tension spring
2 * Throttle tension screw

ADJUSTABLE TRAVEL ANGLE AGO1 Mini features the same travel adjustment as the full size . 380 Cax549 uu TI 380

one gimbal must be set as throttle and one as self-centring before installation in the radio . use the included screw (see parts bag) to hold down the centring lever .
