Description
The Matek SAM-M10Q-5883 GNSS is a cutting-edge multi-constellation GNSS module featuring the advanced u-blox SAM-M10Q platform. It offers exceptional sensitivity and acquisition time for all L1 GNSS signals and can receive concurrent signals from four GNSS, including GPS, GLONASS, Galileo, and BeiDou. Its advanced Super-S technology further enhances RF sensitivity and dynamic position accuracy, even in challenging urban environments. Finally, with the high-gain 15 x 15 mm2 patch antenna provides the best balance between performance and small size. The omnidirectional antenna radiation pattern increases flexibility for device installation. Enjoy reliable readings for your drone navigation!
Check out all our GPS modules, and our full line of Matek products!
Features
- Simple design-in with no RF expertise required
- Less than 38 mW power consumption without compromising GNSS performance
- Maximum position availability with 4 concurrent GNSS reception
- Advanced spoofing and jamming detection
- Pin-compatible with previous SAM-M8Q
Specifications
- GNSS u-blox SAM-M10Q-00B (GPS, GLONASS, Galileo and BeiDou)
- No Magnetic Compass built-in
- Patch antenna 15 x 15 x 4mm
- Input voltage range: 4~9V (5V pad/pin)
- Power consumption: 10mA
- UART baudrate: 9600 default
- Operating Temperatures: -20~80 °C
- UART(TX, RX) interface for GNSS SAM-M10Q-00B
- JST-GH-4P connector (SM04B-GHS-TB). 1.27mm pitch
- GNSS PPS LED, Green. (Solid ON after powering on, blinking(1Hz) when GNSS get 3D fix)
- Protocol: UBX(u-blox) 5Hz/?p=5712#tab-id-6
- u-center Windows
Important Notes
- Compass Alignment(flat mounting): Tilting the magnetometer is strongly discouraged !
- INAV/BetaFLight: compass Arrow forward, set CW 270° Flip when flight controller arrow is facing forward.
- INAV/BetaFLight: compass Arrow backward, set CW 90° Flip when flight controller arrow is facing forward.
- Ardupilot/Mission Planner: Rotation None.
- Make sure to have compass/magnetometer 10cm away from power lines/ESC/motors/iron based material
Includes
- 1x Matek SAM-M10Q-5883 GNSS GPS Module
- 1x JST-GH-4P to JST-GH-4P 20cm silicon wire
