iFlight BLITZ E80 4-IN-1 Pro 80A ESC (G2)
The 1-4 layer power board of the PCB circuit is ultra-thick copper with a thickness of 4OZ, ensuring continuous output under high-power operation. The STM32F051 main control processor with a running frequency of up to 48MHz, combined with a three-in-one driver IC, achieves a faster running speed!
Features:
– Rational layout, countersunk holes on extended solder pads to ensure PCB layer connection
– G071 MCU, 48mHz maximum clock speed;
– TDK MLCC Low ESR ceramic capacitors;
– Top grade PSMN1R0-40YLD MOSFET;
– 8 layers double-sided PCB board
Specifications:
– BLHeliSuite download (BL32): .blheli-configurator/blheli-configurator/releases
– Supports DShot DShot150/300/600/MultiShot/ OneShot etc.
– Constant current：80A，100A（Burst）
– Mounting Holes: 35*35mm/Φ3mm
– Current sensor: Yes, scale 200
– Firmware: IFLIGHT_BLITZ_G2
– Telemetry: Supported
– Weight:65g(±10)
– Volts input: 2-8S
– BEC: No
Package includes:
– 1 x BLITZ E80 4-IN-1 Pro ESC (G2
