Description
With an already impressive lineup of flight controllers, Flywoo has released the GOKU GN405 Nano. An economical and durable stack, the GN405 is packed with features including a barometer, 16MB black box, 6 complete hardware serial ports, I2C functionality, and WS2812 LEDs on each corner.
It is specifically designed to be pin mounted to the GOKU BS13A / 35A 4-in-1 16×16 ESCs but can also be soldered via pads. The programmable WS2812 LED on each corner provides low-profile lighting for this tiny FC
Check out all our 16×16 stacks, and our Flywoo gear selection!
Specifications
GN405 NANO FC
- Dimensions: 22x22mm
- Weight: 2.3g
- Mounting Pattern: 16×16, M3 Holes
- MCU: STM32F405 BGA
- UARTS: 6 1/2/3/4/5/6
- I2C: SCL/SDA
- GYRO: ICM42688
- BARO: BMP280
- BEC: 5V 2A
- LED: 4x WS2812
- FLASH: 8M
- Input Voltage: 2-6S
- Firmware: FLYWOOF405NANO
BS13A 4-IN-1 ESC
