Description

FLYSKY FRM303 2.4GHz TX Module SPECIFICATIONS

Brand Name: NoEnName_Null

Origin: Mainland China

Compatible Audio & Video Equipment Style: Digital-to-Analog Converter (DAC)

Model Number: FLYSKY FRM303 2.4GHz

Quantity: 1 pcs

Wheelbase: Bottom Plate

Size: 75*44*15.5mm

Model Number: FRM303

For Vehicle Type: Airplanes

Tool Supplies: Assembly Category

Four-wheel Drive Attributes: Assemblage

Remote Control Peripherals/Devices: Remote Controller

Upgrade Parts/Accessories: TX Module

RC Parts & Accs: TX

FRM303 can be adjustable in range 14dBM 33dBm(25mW2W) power: XT30 port: 528V/DC Signal port: 4.55.5VIDC Dimensions: 75*44*15.Smm (Antenna and Adapter not included)

The FRM303 features a slim design. measuring 75mm x 44mm x 15.5mm in size and weighing only 65 grams (excluding the antenna and adapter). making it an extremely lightweight transmitter that provides a joyful flying experience.

The FRM303’s metal shell provides excellent heat dissipation. ensuring efficient cooling even during high-power operation.

The FLYSKY FRM303 TX module offers multiple power supply options and an ultra-wide operating voltage range. allowing it to adapt to various power supply environments. Additionally. when powered by a transmitter. the FRM303 can switch seamlessly between its internal and external modules.

The FLYSKY FRM303 TX module boasts an impressive signal recognition capability. ensuring seamless compatibility with a wide range of transmitter brands.

The FRM303 transmitter module offers adjustable transmission power levels. ranging from 25 milliwatts (0.014 dBm) up to 2 watts (33 dBm). providing six power settings: 25 mW. 100 mW. 500 mW. 1 W. and 2 W.

The FRM303 offers advanced features. including high-frequency RF functionality that enables up to 8-channel binding. model switching. failsafe mode. and RSSI (Received Signal Strength Indication) signal strength output for an enhanced user experience.

The FLYSKY FRM303 TX module. compliant with AFHDS3 standards. features a maximum power output of 2W. making it an ideal choice for navigating complex environments and achieving extended range flight distances.

FS-FRAO1. a 2.4GHz fishbone antenna with a 45-degree SMA adapter. connects via an XT30 interface to the FRM303 RF module and FGPZOL (adapter).
