Diatone Mamba DJI F722 APP MK4 30×30 Flight Controller

Description

The Diatone Mamba MK4 is an F722 flight controller. With WiFi capabilities through the SpeedyBee APP, this stack is the perfect addition to your FPV build. This version has an IMC42688P Gyro.

Check out all our 30×30 FCs and all our Diatone Gear!

Specifications

• MCU: STM32F722
• GYRO: IMC42688P
• Barometer: Yes
• OSD: Yes
• Blackbox: 16M Flash Memory
• Uarts: 6Set
• ESC Telemetry: Yes
• Power Led: Yes
• LED Controller: BF LED/MB LED
• F.Port: Yes
• RSSI: Yes
• Buzz: Yes
• Input: 3-6S Lipo
• TVS Protection: Yes
• BEC: 3.3V/0.5A, & 5V/3A, and 9V/3A
• Mounting: 30.5×30.5mm, M3

Includes

• 1x Diatone Mamba DJI F722 APP MK4 30×30 Flight Controller
• 5x M3 ESC Isolation Dampers
• 5x M3 Silicone Dampers
• 1x 6-Pin Air Unit Cable
• 2x 8-Pin Cable

Wiring Diagram
