Description
Phoenix Edge HV 40A ESC – 12S/50.4V, No BEC
The Phoenix Edge HV 40A ESC is a high-performance electronic speed controller designed for RC helicopters and fixed-wing aircraft. It supports up to 12S LiPo (50.4V) and features Castle Link USB compatibility, enabling full programmability and firmware updates.
With advanced telemetry capabilities, data logging, and power system alerts, this ESC provides real-time monitoring and diagnostics. The AUX wire offers programmable functions such as governor gain adjustments, RPM output, and arming lock.
Features:
- 40A continuous current for efficient power delivery
- Supports 3S-12S LiPo (50.4V max)
- Data logging for performance tracking
- Telemetry capable for real-time system monitoring (additional accessories required)
- AUX functionality for governor gain, arming lock, and RPM output
- USB programming via Castle Link Adapter (coupon included)
- Firmware upgradable for future features
- Power system alerts via LED and motor signals
- No BEC included – separate power source required for receiver and servos
Specifications:
- Continuous Current: 40A
- Max Voltage: 50.4V (12S LiPo)
- BEC: Not included
- Dimensions: 1.8″ (L) x 1.7″ (W) x 0.8″ (H)
- Weight: 2.4 oz. (67.2g) with wires / 1.1 oz. (30.6g) without wires
- Receiver Voltage Input Range: 4.8V-9V
- Programmability: Castle Link USB & B-LINK Bluetooth Adapter
Package Includes:
- (1) Phoenix Edge HV 40A ESC
- Coupon for Castle Link USB Adapter
- Coupon for Arming Lockout Key
Reviews
There are no reviews yet.
