Pavo35 Brushless Whoop Frame

Check Out All Our BetaFPV Products!

Elevate your aerial cinematography with this revolutionary 3.5-inch cinematic whoop frame. Engineered with computational fluid dynamics, this frame’s unique duct system is designed to deliver the thrust of a 5-inch drone while maintaining the compact efficiency of 3.5-inch props. It’s the ultimate platform for professionals and enthusiasts seeking stable, powerful, and jello-free HD footage.

Revolutionary Aerodynamic Performance

The standout feature is the proprietary rocket-inspired duct design, which generates an incredible 400g of additional thrust. This massive boost in lift capacity allows your drone to easily carry a full-size action camera like a GoPro Hero 12, providing unparalleled stability and control. The tough PC injection-molded ducts also provide safety for close-proximity flying, making it perfect for capturing dynamic shots near subjects.

Rigid & Vibration-Free Chassis

To handle the increased power, the frame is built around a CNC-machined 7075 aluminum Y-brace. This brace dramatically improves torsional rigidity by up to 60%, eliminating frame flex during aggressive maneuvers. Combined with dedicated vibration-damping balls for both the flight controller and the HD camera mount, this chassis is engineered from the ground up to deliver buttery-smooth footage.

Key Features:

• Boosted Duct Design: Generates +400g of thrust for carrying heavy HD cameras with the stability of a larger drone.
• 7075 Aluminum Y-Brace: Creates an incredibly rigid frame, eliminating flex and vibrations for smooth cinematic video.
• Multi-VTX Compatibility: With 20x20mm and 25.5×25.5mm mounting, it’s ready for any modern digital FPV system like the DJI O3, Walksnail, or Vista.
• Integrated COB LED: A remotely controllable LED provides excellent visibility and a custom aesthetic without extra wiring.
• Fixed XT60 Connector: A secure, frame-mounted power plug prevents your battery lead from being chopped by propellers.
• Comprehensive Kit: Includes all necessary carbon, aluminum, injection-molded ducts, and hardware for a complete build.

Build Recommendations:

• Motors: 2006-2204 series (2400-2800KV)
• VTX: DJI O3 Air Unit, Walksnail Avatar, or Caddx Vista
• Action Cam: GoPro Hero10, Hero11, Hero12, or DJI Action series

Technical Specifications

• Frame Wheelbase: 148mm
• Frame Weight: 113.9g
• Top Plate Thickness: 3mm Carbon Fiber
• Base Plate Thickness: 1.5mm Carbon Fiber
• Motor Mount: 12mm spacing (M2)
• HD Camera Mount: 19mm / 20mm
• Ducts: 92mm Diameter PC Injection-Molded

Package Contents

• 1x Set of T700 Carbon Fiber Plates (Top/Base/Gimbal)
• 1x Set of PC Injection-Molded Ducts (Translucent Gray)
• 1x Set of 7075 Aluminum Y-Brackets and Battery Holders
• 1x Full Hardware Kit (M2/M2.5 screws, nylon nuts)
• 1x Set of Vibration-Damping Balls (for FC and camera)
• 1x COB LED Strip
• 1x Fixed XT60 Connector
