Description
The Plug and Play Argus is AxisFlying electronic series that includes ESC, FC, and stack. Argus PRO series adopt a full aluminum cover wrapped that can get IP54 to protect PCB. Argus series is PCB electronic only. There are 2 kinds of ESC 55A and 65A. The FC is F722 which can support X8.
Check out all our 30×30 FC Stacks, and all our Axis Flying Products!
Specifications
Argus F722 Flight Controller
- MCU: STM32F722RET6
- Gyro: BMI270
- Barometer: Yes
- OSD: Yes
- BEC: 9V/2A, 5V/2A
- UART Ports: 6
- Black Box: 16MB onboard
- Number of supported motors: 8
- Firmware Name: AXISFLYINGF7PRO
- Input Voltage: 3-6S LiPo
- Installation Holes: 30.5×30.5mm M3
32bit 4in1 ESC
- Continuous Current: 55A
- Burst Current: 65A
- Input Voltage: 3-6S
- ESC Target: BLHeli_32 (ST_G0_04)
- Current Proportion value: Scale=400
- PWM Frequency Range: 16-96khz
- Telemetry: Supported
- Ammeter: Supported
- BEC: No
- Installation holes: 30.5×30.5mm
- Dimensions: 48.6x44x6.3mm
- Weight: 16.2g
Includes
- 1x AxisFlying Argus F722 3-6S 30×30 Stack/Combo (F7 FC / 32bit 55A 4in1 ESC)
- 1x Wiring Set
